Product Detail
COMPOSITION: ALU Skin+ XPS+ ALU Skin
EXTERNAL LAYER:
Semi hard aluminum panel
RAW
Chromatized on both sides
Powder painted acc. to RAL
External layers protected with a foil
Suitable for outdoor applications, resistant to atmospheric conditions
CORE:
Fire resistance: B1
Thermal conductivity rate – 0,034 W/(m*K) XPS
| Thickness | [0] |  24 | 36 | 40 | 44 | 48 |
| U* | [W] m2K | 1,22 | 0,85 | 0,77 | 0,72 | 0,66 |
| *Heat transmission rate has been determined by a calculation method | ||||||
AVAILABLE SIZES [mm]: 4000x1500 Maximal
